Steel sheet thickness is quoted as a gauge number, and the numbers run backwards: 10 gauge steel is thicker than 20 gauge. Worse, the gauge scale is not a set of round numbers. 14 gauge is 0.0747 in, which looks arbitrary until you know where it comes from.
It comes from weight. The Manufacturers’ Standard Gauge for sheet steel defines each gauge by its weight per square foot, and the thickness is derived from that. Once you know the rule, the whole table becomes predictable.
Steel Gauge Thickness Chart
| Gauge | Weight (lb/ft²) | Thickness (in) | Thickness (mm) |
|---|---|---|---|
| 7 | 7.500 | 0.1793 | 4.55 |
| 8 | 6.875 | 0.1644 | 4.18 |
| 9 | 6.250 | 0.1495 | 3.80 |
| 10 | 5.625 | 0.1345 | 3.42 |
| 11 | 5.000 | 0.1196 | 3.04 |
| 12 | 4.375 | 0.1046 | 2.66 |
| 13 | 3.750 | 0.0897 | 2.28 |
| 14 | 3.125 | 0.0747 | 1.90 |
| 15 | 2.813 | 0.0673 | 1.71 |
| 16 | 2.500 | 0.0598 | 1.52 |
| 17 | 2.250 | 0.0538 | 1.37 |
| 18 | 2.000 | 0.0478 | 1.21 |
| 19 | 1.750 | 0.0418 | 1.06 |
| 20 | 1.500 | 0.0359 | 0.91 |
| 22 | 1.250 | 0.0299 | 0.76 |
| 24 | 1.000 | 0.0239 | 0.61 |
| 26 | 0.750 | 0.0179 | 0.45 |
| 28 | 0.625 | 0.0149 | 0.38 |
These are uncoated carbon steel sheet values. Galvanized sheet of the same gauge is slightly thicker because the zinc adds to it, and stainless and aluminum use different gauge scales entirely.
The Rule Behind the Numbers
Look at the weight column and the pattern appears immediately. Each step down in gauge number adds a fixed amount of weight, in steps of 0.625, 0.25 or 0.125 lb/ft² depending on where you are in the scale. 24 gauge is exactly 1 lb/ft². 18 gauge is exactly 2. 11 gauge is exactly 5.
The thickness follows from the weight using the standard’s basis of 41.82 lb per square foot for every inch of thickness:
thickness (in) = weight (lb/ft²) ÷ 41.82
Check it on 14 gauge: 3.125 ÷ 41.82 = 0.0747 in. On 16 gauge: 2.5 ÷ 41.82 = 0.0598 in. On 10 gauge: 5.625 ÷ 41.82 = 0.1345 in. Every row in the chart above falls out of that one division, which is a useful thing to be able to do in your head on site.
The 41.82 figure is itself a historical leftover rather than the true density of steel, which works out closer to 40.84 lb/ft² per inch. That small discrepancy is why gauge thickness and a direct weight calculation never quite agree, and why thickness, not gauge, is what belongs on a drawing.
Gauge Is Not a Specification
Because gauge is a trade convention rather than a dimensional standard, it carries a tolerance and it varies by material. Ordering “16 gauge” without saying which material and which standard is how the wrong steel arrives.
| 16 gauge in… | Approximate thickness |
|---|---|
| Carbon steel sheet | 0.0598 in (1.52 mm) |
| Galvanized steel sheet | 0.0635 in (1.61 mm) |
| Stainless steel sheet | 0.0625 in (1.59 mm) |
| Aluminum sheet | 0.0508 in (1.29 mm) |
The spread between the thinnest and thickest of those is about 25 percent for the same nominal number. On a structural member that is the difference between a section that works and one that does not.
Where Gauge Shows Up in Structural Work
Hot-rolled shapes are specified by actual dimensions, never by gauge. You will not see a wide flange beam described in gauge, which is why every figure in the wide flange beam sizes chart is an actual thickness in inches and millimeters.
Gauge belongs to products rolled from sheet: steel floor and roof deck, cold-formed studs and track, purlins and girts, and metal wall panels. Deck in particular is ordered by gauge, and the load a given profile can carry changes with it. The Steel Deck Institute has set industry standards for the design, manufacture and field use of steel deck products since 1939 (checked September 2026), and its load tables are organized around exactly these gauge steps.
The practical consequence: going from 20 gauge to 18 gauge deck adds a third to the steel thickness and a third to the material cost, and it is a decision with a real structural effect rather than a rounding-up.
Why Thin Steel Behaves Differently
A thicker section is not just proportionally stronger. Thin elements can buckle locally, rippling out of plane long before the steel reaches its yield strength, so capacity does not scale linearly with thickness the way intuition suggests.
That is the whole reason cold-formed steel has its own design specification separate from the one used for hot-rolled shapes. Going two gauges thinner to save money can cost more capacity than the thickness ratio implies, and it is not a substitution to make on site.
Thin steel also has less material to lose before corrosion matters, which is why sheet products are so often galvanized. The American Galvanizers Association describes the zinc as giving barrier and cathodic protection plus a zinc patina (checked September 2026). There is more on how that coating behaves in our article on whether galvanized steel rusts.
Frequently Asked Questions
Is a higher gauge number thicker or thinner?
Thinner. The scale counts down as the steel gets heavier, so 10 gauge is roughly three and a half times the thickness of 20 gauge.
How thick is 14 gauge steel?
0.0747 in, or 1.90 mm, for uncoated carbon steel sheet. It weighs 3.125 lb per square foot, which is where that thickness comes from.
Why is there no 21 or 23 gauge?
They exist in the standard but are rarely stocked. Above 20 the commercially available sizes step in twos, because the thickness difference between consecutive odd gauges at that end of the scale is too small to be worth carrying.
Can I measure gauge with calipers?
You can measure the thickness and look it up, which is the practical approach. Remember to allow for coating: a galvanized sheet measures thicker than its bare gauge, and rolling tolerance adds a few thousandths either way.
What gauge is 1/8 inch steel?
Close to 11 gauge, which is 0.1196 in against 0.125 in. Once you are at an eighth of an inch and above, material is normally sold as plate by actual thickness rather than by gauge at all.
The Short Version
Gauge counts backwards because it was built from weight per square foot, not thickness. Divide the weight by 41.82 and you get the inches. It only applies to sheet products, it changes meaning between materials, and it carries a tolerance, so specify the actual thickness whenever the number matters structurally.
